FABRIC / LOONG-FLEX®

SJ200-160S UHMWPE Soft Armor UD.
Technical Profile.

A high-value UHMWPE unidirectional soft armor material designed for NIJ IIIA vests that need a balanced mix of protection, flexibility, and cost efficiency.

SJ200-160S UHMWPE Soft Armor UD

Quick Facts

Brand NameLOONG-FLEX® SA Series (Soft Armor – UHMWPE UD)

Product CodeSJ200-160S

Armor TypeSoft Body Armor

ConstructionUD Cross-Ply Laminate

ApplicationBallistic Vest / Soft Body Armor Panel

Product Summary

A high-value UHMWPE unidirectional soft armor material designed for NIJ IIIA vests that need a balanced mix of protection, flexibility, and cost efficiency.

LOONG-FLEX® is part of Sinofibra's ballistic materials platform, where flexible protection, rigid composite development, and repeatable manufacturing performance are prioritized together. It supports Ballistic Protection and is suited to engineering teams that need material efficiency, scalable conversion, and clear specification control from development to production.

Key Features

Optimal protection-to-cost balance for mainstream soft armor programs
160 gsm 4-ply cross-ply UD with waterborne polyurethane binder
Designed for vest panels with strong multi-hit behavior

Applications

Ballistic vest panels
Soft body armor inserts
General police and security armor systems

Technical Specifications

Organized into grouped sections so engineering teams can review product setup, physical properties, and ballistic performance more efficiently.

REV. 2026.Q2

Product Configuration

Brand NameLOONG-FLEX® SA Series (Soft Armor – UHMWPE UD)

Product CodeSJ200-160S

Armor TypeSoft Body Armor

ConstructionUD Cross-Ply Laminate

ApplicationBallistic Vest / Soft Body Armor Panel

Product FormRoll

Physical & Material Data

Areal Density (with film)160 g/m² ± 5 g/m²

Fabric Width1600 mm

Roll Length100 m (standard) / Customizable

Fiber TypeUHMWPE — SJ200 Grade

Fiber Tenacity35 – 38.5 cN/dtex

Matrix / BinderWaterborne Polyurethane (WPU)

Ballistic & Process Performance

Flexibility Rating++

Key AdvantageHigh-tenacity mid-grade UHMWPE UD; optimal balance of protection, weight and cost for NIJ IIIA vests

Resin SystemWaterborne polyurethane — low VOC, eco-friendly

Multi-hit CapabilityGood resistance to multiple fragment impacts

ProcessingCompatible with standard hot-press lamination

NIJ IIIA 9mm25 Plies 4.00 kg/m²

NIJ IIIA .44 Magnum32 Plies 5.12 kg/m²

GA141 Level 222 Plies 3.52 kg/m²

GA141 Level 332 Plies 5.12 kg/m²

Anti-Trauma Material++

V50650 ± 15 m/s

Catalog Position

BrandLOONG-FLEX®

TemplateFABRIC

SolutionsBallistic Protection

CategoryUD Fabric

Download Center

Download the full PDF TDS for complete testing conditions, processing notes, and engineering details.

Download Full PDF TDS
